AIC-3000-DL-DIS-KIT — 3000W Dual-Leg Advanced Inverter Charger Package
Built for RVs that demand more. The AIC-3000-DL-DIS-KIT pairs the Go Power! 3000W Dual-Leg Advanced Inverter Charger with the PowerTrak™ Display and every RV-C cable and harness required for a complete installation. With a 50A built-in transfer switch and full PowerTrak™ integration, this is the all-in-one package for high-capacity RV power upgrades — one part number, one box, ready to install.
PowerTrak™ Connected
The AIC-3000-DL-DIS-KIT uses built-in RV-C communication to integrate with the full PowerTrak™ ecosystem, including:
- Go Power! Advanced Lithium Batteries
- Battery Manager Kit
- Dometic MPPT Solar Controllers
Mobile App Control
Monitor and control your entire power system from your phone. The Go Power! Connect / Dometic Power app (iOS & Android) gives you real-time solar charging stats, battery levels, power consumption, inverter settings, and charging parameters — all from your mobile device.
FEATURES
Package Includes
- AIC-3000-12-DL 3000W Dual-Leg Advanced Inverter Charger
- PowerTrak™ Display
- 25 ft RV-C extension cable
- RV-C harnesses and accessories required for installation
- Quick Start Guide
Key Features
- 3000W continuous power output
- 150A battery charger with multi-stage charging support
- 50A built-in transfer switch — dual-leg for higher-capacity RV systems
- UL Listed
- 3-year warranty
Built-In Protections
- AC overvoltage & undervoltage
- AC overcurrent, over frequency & under frequency
- AC output overload & short circuit
- DC overvoltage & undervoltage
- Over temperature
SPECIFICATIONS
AIC-3000-12-DL Inverter Charger
| Input Voltage Waveform | Sinusoidal (utility or generator) |
|---|---|
| Nominal Input Voltage | 120 VAC |
| AC Input Voltage Range | 65-140 VAC |
| Nominal Input Frequency | 60 Hz |
| Input Frequency Range | 55-65 Hz |
| Transfer Time | < 20 ms |
| Max AC Input Current | 50 A |
| Nominal DC Voltage | 12 VDC |
| HBCO/HBCI | 16.5/15 VDC |
| LBCO/LBCI | 10.5/12.5 VDC (programmable) |
| Max DC Input Voltage | 17 VDC |
| THDV | < 3% @ Nominal Voltage |
| Continuous Power | 3000 W |
| Surge Power (200 ms) | 6000 W |
| Surge Power (5 s) | 4800 W |
| Surge Power (5 min) | 3300 W |
| Output Frequency | 60 Hz (programmable) |
| Output Voltage | 120 VAC (programmable) |
| Output Waveform | Pure Sine Wave |
| Peak Efficiency | > 85% |
| No Load Power Consumption | < 25 W @ 12.5 VDC |
| Stand-By Power Consumption (Inverter Disabled) | < 15 W @ 12.5 VDC |
| Hibernation Mode Consumption | < 2 W @ 12.5 VDC |
| Max Charging Current | 150 A |
| Multi-stage Charging | Bulk, Absorption, Float, Equalize |
| Temperature Compensation | External battery sensor: -25 mV/°C |
| Operating Temperature (without derating) | -20 °C to 40 °C (-4 °F to 104 °F) |
| Operating Temperature (with derating) | -20 °C to 60 °C (-4 °F to 140 °F) |
| Relative Humidity | 5% to 95% non-condensing |
| Storage Temperature | -20 °C to 60 °C (-4 °F to 140 °F) |
| Certifications | FCC Class B Part 15, Industry Canada ICES-003 Class B, UL 458, CSA 107.1, ABYC A31, ABYC E11 |
| Dimensions (L x W x H) | 19.7 x 11.3 x 4.4 in (499 x 288 x 112 mm) |
| Net Weight | 21.7 lbs (9.84 kg) |
| Warranty | 3 years |
