PRODUCT DETAILS
The 16 in (400 mm) Advanced Lithium data cable (GP-ADV-BC-400) links a Go Power! Advanced Lithium battery to the next battery or to the PowerTrak™ network. Go Power! Advanced Lithium batteries report voltage, current, temperature and state of charge straight to the PowerTrak™ display — no shunt needed — but each battery must be cabled into the data network. Use one cable per battery and finish each cable run with a GP-RVC-BCR end-cap terminator.
Built to the standard RV manufacturers install
Go Power! has designed mobile power since 1996 and is the power brand fitted at the factory by Jayco, Forest River, Thor and other leading RV builders. PowerTrak™ is the RV-C display system that ties those components together — solar controller, inverter/charger, lithium batteries and shunt on one screen — and the same parts are available here for retrofits and upgrades. Backed by a North American support team (part of Dometic).
FEATURES
WHAT IT RUNS
SPECIFICATIONS
| Model / SKU | GP-ADV-BC-400 / 83141 |
|---|---|
| Length | 16 in (400 mm) |
| Use | Battery-to-battery or battery-to-network data link, Advanced Lithium |
| Pair with | GP-RVC-BCR terminator |
COMPARE MODELS
PowerTrak™ is a plug-together RV-C network. Use this table to pick the part you need; if you are starting from nothing, the Display Kit or Battery Manager Kit includes the harness and terminator.
| Part | Model | What it is | Use it when |
|---|---|---|---|
| PowerTrak™ Display Kit | GP-PT-DIS-KIT | Display + 25 ft harness + terminating resistor | Starting a PowerTrak system from scratch |
| PowerTrak™ Display Only | GP-PT-DIS-3 | 3.2 in touchscreen, Bluetooth | Adding a display to a coach that already has the harness, or a second screen |
| Battery Manager Kit | GP-BMG | Display + 500A smart shunt + 25 ft harness + terminating resistor | Monitoring AGM, flooded or non-Go Power! lithium batteries |
| Smart Shunt 275A/500A | GP-SHUNT-500 | Shunt only | Adding battery state of charge to an existing display |
| Display Extension Harness, 25 ft | GP-RVC-EXT-25 | Male-to-male RV-C cable | Reaching from the power bay to a display in the living area |
| Extension Cable, 5 ft M-F | GP-RVC-EXT-MF5 | Male-to-female RV-C cable | Adding a few feet to an existing run |
| Branch Connector Harness | GP-RVC-PT-BC | RV-C tee, 300 mm / 100 mm legs | Adding another device to the network |
| Terminating Resistor Harness | GP-RVC-PT-TR | RV-C network terminator | One per PowerTrak system, at the battery/shunt end |
| Advanced Lithium Data Cable, 16 in | GP-ADV-BC-400 | Battery-to-battery / battery-to-network data cable | Networking Go Power! Advanced Lithium batteries (short run) |
| Advanced Lithium Data Cable, 24 in | GP-ADV-BC-600 | Battery-to-battery / battery-to-network data cable | Networking Go Power! Advanced Lithium batteries (longer run) |
| Lithium Battery Data Terminating Resistor | GP-RVC-BCR | End-cap terminator for the battery data port | One per networked Advanced Lithium battery cable; two with 2+ batteries |
MANUALS, SAFETY INFORMATION AND DOWNLOADS
ACCESSORIES
FAQ
Which batteries use this cable?
Go Power! Sun Cycle® Advanced Lithium batteries (100Ah, SKU 83156, and 300Ah, SKU 83240). Standard lithium or AGM batteries have no data port and use the GP-SHUNT-500 instead.
How many cables and terminators do I need?
One data cable per battery, plus one GP-RVC-BCR terminator when a single battery is networked and two when two or more batteries are linked.
Do I still need a shunt?
No. Advanced Lithium batteries send state of charge over RV-C, so the shunt is unnecessary.
16 in or 24 in?
Measure from the battery data port to the next battery or to your network branch. Use the 16 in (400 mm) for batteries side by side and the 24 in (600 mm) when there is a gap or the batteries are larger.
Is PowerTrak what my RV came with?
Go Power! has supplied RV manufacturers since 1996 and is fitted at the factory by Jayco, Forest River, Thor and many other brands. PowerTrak™ is the RV-C display system used with those Go Power! and Dometic components, so these are the same parts your dealer would order.
